Description
HEACOTEX CPCB Constant Wattage Cable
HEACOTEX CPCB is a constant-power, double-conductor heating cable for industrial refrigeration — especially cold rooms. The heating section is clearly identified by connection points marked with a continuous black line at 500 mm intervals. The cable is supplied to specification or per metre and is fitted with an external metal braiding for additional mechanical protection and earthing.
Features
- Constant power output — uniform heat along the full circuit
- Double-conductor parallel construction
- Connection points marked every 500 mm for accurate cut-to-zone
- External tinned-copper metal braid for mechanical protection and earthing
- Supplied per metre or to specification
Specifications
| Supply voltage | 12 V to 400 V |
|---|---|
| Specific power | 40 / 65 W/m |
| External dimensions (with or without metal mesh) | 7 × 5 mm ± 0.5 mm |
| Operating temperature range | −60°C to +200°C (+230°C for short periods) |
| Minimum bending radius | 15 mm |
| Standard insulations | According to technical drawing |
Application
Commercial and industrial refrigeration; conditioning; animal housing; medical and scientific facilities; floriculture; sport and wellness installations.
Contact Heacotex with your installation details — cold-room dimensions, supply voltage and required wattage — for circuit length and accessory advice.
